Receive lossless HD video from up to 750′ line-of-sight with the Bolt 6 RX 750 Monitor Module with Internal Antennas from Teradek. This module mounts onto the back of a SmallHD Cine 7, Indie 7, or 702 Touch monitor and can wirelessly receive up to 4K30 video with 10-bit 4:2:2 HDR support and outputs video via one HDMI port. It features five internal antennas and includes a battery plate to power the receiver using a professional Gold mount battery. Though it can transmit visually lossless video to any Bolt 4K series receiver with zero delay using the 5 GHz band, it requires a Bolt 6 device to transmit over the 6 GHz band.

Internal Antennas
Five internal 2 dBi antennas provide this receiver with a rugged, compact design.
Encryption and Timecode
The Bolt 6 RX 750 Monitor Module features improved metadata, range, and compatibility over its predecessors. The built-in AES-256 encryption with RSA 1024 key pairing protects your video from prying eyes, while noise rejection keeps your video clean no matter how many devices are using the wireless spectrum. The Bolt 6 system also supports the transmission of timecode and start/stop triggers from the camera.
Software and Mobile Apps
The receiver module also supports a desktop Bolt Manager software application or the Bolt app for iOS or Android that easily connects via Bluetooth, which both provide a spectrum analyzer, channel selection tools, and remote configuration.
Key Features
Supports the new freely available 6 GHz wireless frequency band.
Cross-compatible with all Bolt 4K and 4K LT series 5 GHz transmitters.
Mounts on the back of a SmallHD Cine 7, Indie 7, or 702 Touch monitor.
Wirelessly receive up to 4K30 video and output up to 4K30 via HDMI 2.0 port.
Gold mount battery plate included.
Supports Rec 2020 HDR in 10-bit 4:2:2 color gamut.
Smaller and lighter chassis design than other Bolt receivers.
AES-256 encryption and RSA 1024 key pairing support.
Wireless Android/iOS app via Bluetooth features a spectrum analyzer and remote configuration.
